今回も、前回の続きを書こうと思います。Windbgでブルースクリーンが発生したサーバのハードウェアの情報を確認するコマンドについて書こうと思います。ダンプからサーバの型番やCPU、BIOS情報を見ることができます。
１．!sysinfo cpuinfoコマンド
このコマンドはダンプを取得した機器のCPU情報を表示するコマンドです。
コマンド実行例
0: kd> !sysinfo cpuinfo
[CPU Information]
~MHz = REG_DWORD 2000
Component Information = REG_BINARY 0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0
Configuration Data = REG_FULL_RESOURCE_DESCRIPTOR ff,ff,ff,ff,ff,ff,ff,ff,0,0,0,0,0,0,0,0
Identifier = REG_SZ x86 Family 6 Model 14 Stepping 12
ProcessorNameString = REG_SZ Intel(R) Core(TM) Duo CPU T2500 @ 2.00GHz
Update Signature = REG_BINARY 0,0,0,0,54,0,0,0
Update Status = REG_DWORD 2
VendorIdentifier = REG_SZ GenuineIntel
MSR8B = REG_QWORD 5400000000
２．!sysinfo cpuspeedコマンド
このコマンドはダンプを取得した機器のCPU処理速度を表示するコマンドです。
コマンド実行例
CPUID: "Intel(R) Core(TM) Duo CPU T2500 @ 2.00GHz"
MaxSpeed: 2000
CurrentSpeed: 2000
３．!sysinfo machineidコマンド
このコマンドはダンプを取得した機器のシステムボード情報を表示するコマンドです。
コマンド実行例
Machine ID Information [From Smbios 2.4, DMIVersion 0, Size=1412]
BiosVendor = Phoenix Technologies LTD
BiosVersion = 3.0.0017
BiosReleaseDate = 03/28/2007
SystemManufacturer = NEC
SystemProductName = Express5800/i110Rb-1h [N8100-1233]
SystemVersion = FR1.9
BaseBoardManufacturer = MICRO-STAR
BaseBoardProduct = MS-9635
BaseBoardVersion = 010
４．!sysinfo smbiosコマンド
このコマンドはダンプを取得した機器の情報をツリー状に表示するコマンドです。インストールされているBIOS、CPU、メモリなどを確認できます。
コマンド実行例
0: kd> !sysinfo smbios
[SMBIOS Data Tables v2.4]
[DMI Version - 0]
[2.0 Calling Convention - No]
[Table Size - 1412 bytes]
[BIOS Information (Type 0) - Length 24 - Handle 0000h]
Vendor Phoenix Technologies LTD
BIOS Version 3.0.0017
BIOS Starting Address Segment e048
BIOS Release Date 03/28/2007
BIOS ROM Size 100000
BIOS Characteristics
07: - PCI Supported
09: - Plug and Play Supported
11: - Upgradeable FLASH BIOS
12: - BIOS Shadowing Supported
14: - ESCD Supported
15: - CD-Boot Supported
16: - Selectable Boot Supported
19: - EDD Supported
20: - NEC 9800 J-Floppy Supported
26: - Print Screen Device Supported
27: - Keyboard Services Supported
28: - Serial Services Supported
BIOS Characteristic Extensions
00: - ACPI Supported
01: - USB Legacy Supported
08: - BIOS Boot Specification Supported
09: - Fn-Key NET-Boot Supported
10: - Specification Reserved
BIOS Major Revision 255
BIOS Minor Revision 255
EC Firmware Major Revision 255
EC Firmware Minor Revision 255
[System Information (Type 1) - Length 27 - Handle 0001h]
Manufacturer NEC
Product Name Express5800/i110Rb-1h [N8100-1233]
Version FR1.9
Serial Number
UUID 00000000-0000-0000-0000-000000000000
Wakeup Type Unknown
SKUNumber [String Not Specified]
Family [String Not Specified]
[BaseBoard Information (Type 2) - Length 8 - Handle 0002h]
Manufacturer MICRO-STAR
Product MS-9635
Version 010
Serial Number
[System Enclosure (Type 3) - Length 17 - Handle 0003h]
Manufacturer
Chassis Type Rack Mount Chassis
Version 856-126484-201
Serial Number
Asset Tag Number
Bootup State Safe
Power Supply State Unknown
Thermal State Safe
Security Status Unknown
OEM Defined 0
[Processor Information (Type 4) - Length 35 - Handle 0004h]
Socket Designation CPU#1
Processor Type Central Processor
Processor Family 01h - Other
Processor Manufacturer Intel Corporation
Processor ID ec060000fffbe9bf
Processor Version Intel(R) Core(TM) Duo CPU T2500 @ 2.00GHz
Processor Voltage 8ah - 1.0V
External Clock 166MHz
Max Speed 2330MHz
Current Speed 2000MHz
Status Enabled Populated
Processor Upgrade Other
L1 Cache Handle 0005h
L2 Cache Handle 0006h
L3 Cache Handle [Not Present]
Serial Number
Asset Tag Number
Part Number
[Cache Information (Type 7) - Length 19 - Handle 0005h]
Socket Designation L1 Cache for CPU#1
Cache Configuration 0180h - WB Enabled Int NonSocketed L1
Maximum Cache Size 0040h - 64K
Installed Size 0040h - 64K
Supported SRAM Type 0018h - Burst Pipeline-Burst
Current SRAM Type 0018h - Burst Pipeline-Burst
Cache Speed 0ns
Error Correction Type Multi-Bit ECC
System Cache Type Data
Associativity 4-way Set-Associative
[Cache Information (Type 7) - Length 19 - Handle 0006h]
Socket Designation L2 Cache for CPU#1
Cache Configuration 0181h - WB Enabled Int NonSocketed L2
Maximum Cache Size 1000h - 4096K
Installed Size 1000h - 4096K
Supported SRAM Type 0018h - Burst Pipeline-Burst
Current SRAM Type 0008h - Burst
Cache Speed 0ns
Error Correction Type Multi-Bit ECC
System Cache Type Unified
Associativity 4-way Set-Associative
[Onboard Devices Information (Type 10) - Length 6 - Handle 0013h]
Number of Devices 1
01: Type Video [enabled]
01: Description VGA
[Onboard Devices Information (Type 10) - Length 6 - Handle 0014h]
Number of Devices 1
01: Type Ethernet [enabled]
01: Description LAN1
[Onboard Devices Information (Type 10) - Length 6 - Handle 0015h]
Number of Devices 1
01: Type Ethernet [enabled]
01: Description LAN2
[OEM Strings (Type 11) - Length 5 - Handle 0016h]
Number of Strings 2
1 HWID=041D
2 NEC_Product
[System Configuration Options (Type 12) - Length 5 - Handle 0017h]
[Physical Memory Array (Type 16) - Length 15 - Handle 0019h]
Location 03h - SystemBoard/Motherboard
Use 03h - System Memory
Memory Error Correction 05h - Single-bit ECC
Maximum Capacity 4194304KB
Memory Error Inf Handle [No Errors]
Number of Memory Devices 2
[Memory Device (Type 17) - Length 27 - Handle 001ah]
Physical Memory Array Handle 0019h
Memory Error Info Handle [No Errors]
Total Width 72 bits
Data Width 64 bits
Size 1024MB
Form Factor 09h - DIMM
Device Set 01h
Device Locator DIMM 1
Bank Locator BANK 1
Memory Type 13h - Specification Reserved
Type Detail 0080h - Synchronous
Speed 400MHz
Manufacturer 7F7FFE0000000000
Serial Number
Asset Tag Number
Part Number EBE10RD4AGFA-4A-E
[Memory Device (Type 17) - Length 27 - Handle 001bh]
Physical Memory Array Handle 0019h
Memory Error Info Handle [No Errors]
Total Width 72 bits
Data Width 64 bits
Size 1024MB
Form Factor 09h - DIMM
Device Set 02h
Device Locator DIMM 2
Bank Locator BANK 2
Memory Type 13h - Specification Reserved
Type Detail 0080h - Synchronous
Speed 400MHz
Manufacturer 7F7FFE0000000000
Serial Number
Asset Tag Number
Part Number EBE10RD4AGFA-4A-E
[32Bit Memory Error Information (Type 18) - Length 23 - Handle 001ch]
[32Bit Memory Error Information (Type 18) - Length 23 - Handle 001dh]
[Memory Array Mapped Address (Type 19) - Length 15 - Handle 001eh]
Starting Address 00000000h
Ending Address 001fffffh
Memory Array Handle 0019h
Partition Width 01
[Memory Device Mapped Address (Type 20) - Length 19 - Handle 001fh]
Starting Address 00000000h
Ending Address 000fffffh
Memory Device Handle 001ah
Mem Array Mapped Adr Handle 001eh
Partition Row Position 01
Interleave Position [None]
Interleave Data Depth [None]
[Memory Device Mapped Address (Type 20) - Length 19 - Handle 0020h]
Starting Address 00100000h
Ending Address 001fffffh
Memory Device Handle 001bh
Mem Array Mapped Adr Handle 001eh
Partition Row Position 02
Interleave Position [None]
Interleave Data Depth [None]
